Sundown Audio Uv.2 12" Subwoofer
$421.19 USD
$623.99
Unit price
/
Unavailable
Sundown Audio Uv.2 12" Subwoofer - D2 is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Subscribe to our newsletter
Sign up for exclusive offers.
Sundown Audio Uv.2 12" Subwoofer
$421.19 USD
$623.99
Unit price
/
Unavailable
Description
Description
Sundown audio Uv.2 12" Subwoofer 1750 RMS
Features (U-10 / 12 / 15 / 18)
- Black Aluminum 3” voice coil former for superior heat dissipation
- High Temperature Round-Wire CCAW voice coil with high-temp black adhesive
- Double stitched surround
- Heavy duty cast basket
- Spring loaded terminals accept up to 8 gauge
- Stitched-on double-XL tinsel leads
- Rear vented pole piece
- Rear drilled gap-venting
- Innovative high-velocity cast aluminum vented frame spacer ring
- Magnet ID shorting ring
- Top-Plate Cooling Channels
- Cast Aluminum surround bolt-on rings
- Optimized for small ported or bandpass enclosures
U-12
| T/S SPECS | U 12" D2 | U 12" D4 |
|---|---|---|
| RE (Ohms) | 3.8 | 6.1 |
| FS (Hz) | 42.2 | 40.0 |
| VAS (L) | 17.9 | 12.3 |
| Qes | 0.30 | 0.38 |
| Qms | 2.67 | 2.93 |
| Qts | 0.27 | 0.34 |
| Le (mH) | 2.41 | 3.67 |
| BL (NA) | 31.2 | 33.7 |
| Mms (Grams) | 290.2 | 284.5 |
| Cms (uM/N) | 0.05 | 0.06 |
| Sens (dB @ 1w/1m) | 88.4db | 85.0db |
U-12
| Sealed Enclosure | 1.0 cu ft |
| Ported Enclosure | 2.0 cu ft |
| Recommended Tuning | 35Hz |
| Recommended Port Area | 32 sq in |
| Displacement | 0.21 cu ft |
| Depth | 7.75″ |
| Outside Diameter | 12.83″ |
| Cut-Out | 11.01″ |
