DC Audio NEO Elite 4.0 Subwoofers
DC Audio NEO Elite 4.0 Subwoofers - d1 / 18 inch is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Description
Description
DC Audio Neo Elite 4.0 Subwoofer
Neo Elite 4.0 Subwoofer Line — engineered for SPL competition and high-power ground pounder builds with massive output and control.
Next-Gen Neo Power for Crushing Lows
The Neo Elite 4.0 answers the call for a 4″-coil Neo-powered subwoofer that’s as happy in the SPL lanes as it is pounding out daily lows. A large flat-wound 4″ coil, 10″ spaced spiders, the proven DC heavy-duty aluminum frame, and a 6-column Neo motor deliver high efficiency, cooling, and control under extreme power. The 2024 update ships stock with the LR cone & surround for durability and performance.
Key Features
- Extremely strong kraft pulp fiber reinforced cone
- Wide long-throw foam surround
- Dome polypropylene dust cover with white DC logo
- 10″ OD spaced spiders
- Extra heavy-duty sewn tinsel lead wire
- Cast DC Series aluminum black frame (no invert mount)
- FEA-analyzed & fully CNC-machined motor assembly
- Rubber mounting gasket
- 8 AWG OFC direct leads
- 4.0″ 8-layer hi-temp aluminum voice coil on black anodized aluminum former
Specifications
| Spec | 15″ | 18″ |
|---|---|---|
| Mounting Depth | 12″ | 13″ |
| Mounting Hole Diameter | 14.25″ | 16.90″ |
| Outside Driver Diameter | 15.7″ | 18.5″ |
| Voice Coil Diameter | 4.0″ | 4.0″ |
| Displacement | 0.23 ft³ | 0.26 ft³ |
| Power Handling (RMS/Peak) | 4500 / 9000 W | 4500 / 9000 W |
| Impedance Options (Dual) | d0.7 / d1 / d2 / d4 | d0.7 / d1 / d2 / d4 |
| Xmax | 34 mm | 34 mm |
| Recommended Ported Box | 3.0 ft³ | 5.5 ft³ |
| Recommended Sealed Box | N/A | N/A |
T/S Parameters
| Parameter | 15″ | 18″ |
|---|---|---|
| Sd | 815 cm² | 1159 cm² |
| Vas | N/A | 67.10 L |
| Cms | N/A | 34.01 μm/N |
| Mms | N/A | 807.49 g |
| Fs | N/A | 30.36 Hz |
| Bl | N/A | 40.55 N·A |
| Re | N/A | 3.9 Ω |
| Le | N/A | 4.70 mH |
| Qms | N/A | 8.08 |
| Qes | N/A | 0.36 |
| Qts | N/A | 0.35 |
| Ref SPL @1W | N/A | 88.83 dB |
Order the DC Audio Neo Elite 4.0
Choose 15″ or 18″ to match your build. The Neo Elite 4.0 brings serious power handling, a high-efficiency Neo motor, and the updated LR cone/surround (2024) to deliver loud, low, and reliable performance for SPL and daily ground-pounding systems.
